Home >> Products >>Drop stitch material >>Weaved Drop Stitch fabric >> Excellent material high strength weaved drop stitch fabric
Product Detail

Excellent material high strength weaved drop stitch fabric

Collect
  • DETAILS

Quick Details

  • Material: 100% Polyester, 100% Polyester
  • Supply Type: Make-to-Order, Make-to-order
  • Type: coated fabric
  • Pattern: Coated, Coated
  • Coated Type: PVC Laminated, PVC laminated
  • Style: Plain
  • Width: up to 3.2m, 1M, 1.55M, 2M
  • Technics: Woven
  • Feature: Flame Retardant, Shrink-Resistant, Tear-Resistant, Waterproof, Waterproof,Flame Retardant,Tear-Resistant
  • Use: Mattress, air deck,surfboard,bed matress,sup board, Car,Bedding,Mattress,Inflatable boat bottom, Surfing
  • Certification: EN, SGS, ISO9001-2001 ISO14001-2004 and ISO18001-2001
  • Yarn Count: 500D*500D
  • Weight: 2200-3300gsm, 22200-3300gsmGSM
  • Density: other
  • Model Number: HSTC-drop stitch 007

Packaging & Delivery

Packaging Details:PE+hard tube/kraft paper
Delivery Detail:15days

Product description



Product

5cm 8cm10cm12cm15cm20cm
Pattern

DotWaveDot ,In-lineDotDot ,In-lineDot
Base Cloth

Polyester 500D( High tensile)Polyester 500D( High tensile)Polyester 500D( High tensile)Polyester 500D( High tensile)Polyester 500D( High tensile)Polyester 500D( High tensile)
Space Length
cm5 (+/-5%)8 (+/-5%)10 (+/-5%)12 (+/-5%)15 (+/-5%)20
Material Total Weight
g/sq.m2700 (+/-200)2700 (+/-200)2700 (+/-200)2700 (+/-200)2700 (+/-200)2700 (+/-200)
Tensile Strength (2 layers)
N/5cm4100 x 2800 (+/-300)4100 x 2800 (+/-300)4100 x 2800 (+/-300)4100 x 2800 (+/-300)4100 x 2800 (+/-300)4100 x 2800 (+/-300)
Adhesion Strength (2 layers)
N/5cm150 x 150 (+/-20)150 x 150 (+/-20)150 x 150 (+/-20)150 x 150 (+/-20)150 x 150 (+/-20)150 x 150 (+/-20)
Pressure RecommendedPSI(lbs/inch2)151515151515
MaximumPSI(lbs/inch2)
303030303030
Standard Width
Metre
2.061.55/1.681.68/1.851.68/1.852.03
Surface

MattMattMattMattMattMatt
Length (standard)
Metre30,100,150,25030,100,150,25030,100,150,25030,100,150,25030,100,150,250



Applications:

1)  Inflatable boat bottom

2) Surfing board

3) Air mat

4) Bed mattress, Inflatable Gymnasium mats

5) Inflatable swimming pool

Double wall fabric  is featured by high strength, excellent quality stability and self-cleaning of surface, anti-aging and various weather resistance performance. They are widely used for Inflatable SUPs, boat bottom, Mattress, swimming pool, etc.. And our drop stitch fabeic have many variations and types either in regard to colors, width or degree of flame-retardant finishing.
